ZJX0.2-1.5X1250 Simple Hydraulic Slitting Line

Zipper closure 1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout
Product Details
Technical parameters

NO. Name Unit Parameters
1 Control model
Frequency conversion control
2 Materials
Cold rolled steel, Galvanized steel
3 Thickness mm 0. 2-1.5
4 Width mm 1250
5 Coil I.D. mm 480-520
6 Coil O.D. mm ≤1400
7 Weight T 8
8 Slitting blade shaft mm Φ120
9 Blade specification mm Φ220×Φ120×10
10 Material of blade
11 Line speed m/min ≤40
12 Power of decoiler KW 11
13 Power of slitting machine KW 15
14 Power of recoiler KW 30
15 Quantity of strips (Max)
1.5mm, 10pcs
16 Width tolerance
≤±0.05 mm
17 The direction of whole line
from right to left, the operate table faces the machines
18 Power
380V/3Ph/50Hz( Customized)
19 Operation people
1 technician and 1 general worker
20 Color
Blue ( Customized)

Composed devices

1.Hydraulic coil Car (1.5KW)

2 guide pillars.

3. Hydraulic de-coiler (11KW)

4. Slitting machine (15KW)

5. Scrap Winder (4KW)

6.Hydraulic Tension stand

7. Hydraulic recoiler (30KW)
