0.5-1.0mm Galvanized Steel Z Clip Roll Forming Machine KR Building Material for Roof Panel Base
description1
Zipper closure
1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in
place during workout
Description
This 0.5-1.0mm Galvanized Steel Z Clip Roll Forming Machine is specially designed for producing high-precision Z-shaped clips (also known as roof clips/standing seam clips) used in building and roofing systems. It processes galvanized steel coils from 0.5mm to 1.0mm thickness through continuous roll forming, punching, and cutting, delivering finished clips with consistent dimensions and excellent corrosion resistance.
With PLC control and automatic operation, it ensures stable production, high efficiency, and low labor cost, making it ideal for large-scale construction material manufacturing.
Machine List:
|
S.N
|
Equipment name
|
Quantity
|
|
1
|
3 ton passive de-coiler
|
1 set
|
|
2
|
Main roll forming machine
|
1 set
|
|
3
|
Hydraulic Cutting Device
|
1 unit
|
|
4
|
PLC Control box
|
1 unit
|
|
5
|
Hydraulic station
|
1 unit
|
|
6
|
Out table
|
1 set
|
|
7
|
Safety cover
|
1 set
|
Machine Specification:
|
1
|
Material Thickness
|
thickness 0.5 mm-1.0 mm galvanized steel
|
||
|
2
|
Working Speed
|
About 10-12m/min
|
||
|
3
|
Forming Steps
|
About 16-18 stations
|
||
|
4
|
Material of Roller
|
Cr40 Steel with quenching
|
||
|
5
|
Driven system
|
1 inch single chain
|
||
|
6
|
Main motor power
|
5.5 KW
|
||
|
7
|
Cutting type
|
Hydraulic cutting
|
||
|
8
|
Material of cutting
|
CR12 with quench treatment
|
||
|
9
|
Electronic control
|
PLC control
|
||
|
10
|
Hydraulic Station Power
|
4 kw
|
||
Application
Application
-
Roofing Engineering Mainly used for fixing and connecting standing seam metal roof panels, effectively enhance roof installation firmness and wind resistance.
-
Building Envelope System Match various color steel roof and wall panel installation, realize stable positioning and fastening of building enclosure profiles.
-
Light Steel Structure Projects Widely applied in prefab houses, steel structure factories, warehouses and workshops for auxiliary connection and fixing.
-
Commercial & Civil Construction Fit for hotels, villas, residential buildings and public facilities roof and wall auxiliary fitting construction.
-
Construction Accessories Manufacturing Ideal equipment for professional building hardware factories to produce standard roof fasteners in batches.
