0.35-0.8mm G550 PPGI Color Coated Steel Double Layer Roof Panel Roll Forming Machine
description1
Zipper closure
1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in
place during workout
Description
This double layer zigzag fence panel roll forming machine is specially designed for producing various zigzag metal fence panels, adopting 0.35-0.8mm PPGI and color coated steel as raw materials. It integrates uncoiling, leveling, roll forming, and cutting into one automatic production line.
Equipped with PLC intelligent control system, the machine features stable operation, high forming precision and easy parameter adjustment. The double-layer combined design saves workshop space and improves production efficiency greatly. Finished fence panels have smooth surface, uniform size and strong durability, widely applicable for garden isolation, residential boundary, farm enclosure, highway and security protection fencing projects.
With solid machine frame, wear-resistant forming rollers and long service life, it is an ideal professional equipment for metal fence manufacturing factories to mass produce high-quality zigzag fence panels.
Equipped with PLC intelligent control system, the machine features stable operation, high forming precision and easy parameter adjustment. The double-layer combined design saves workshop space and improves production efficiency greatly. Finished fence panels have smooth surface, uniform size and strong durability, widely applicable for garden isolation, residential boundary, farm enclosure, highway and security protection fencing projects.
With solid machine frame, wear-resistant forming rollers and long service life, it is an ideal professional equipment for metal fence manufacturing factories to mass produce high-quality zigzag fence panels.
Machine List:
|
S.N
|
Equipment name
|
Quantity
|
|
1
|
5 tons passive de-coiler
|
1 set
|
|
2
|
Feeding with guide
|
1 set
|
|
3
|
Main roll forming machine
|
1 set
|
|
4
|
Hydraulic Cutting Device
|
1 unit
|
|
5
|
PLC Control box
|
1 unit
|
|
6
|
Hydraulic station
|
1 unit
|
|
7
|
Out tables
|
2units
|
|
8
|
Safety cover
|
1 set
|
|
9
|
Spare parts
|
1 Package
|
|
10
|
Trailer
|
1 set
|
Machine Specification:
|
1
|
Material Thickness
|
thickness 0.35 mm to 0.8mm ,Color Coated Galvanized Steel
|
||
|
2
|
Working Speed
|
About 8-12m/min
|
||
|
3
|
Forming Steps
|
About 18 stations
|
||
|
4
|
Material of Roller
|
45# forge steel, coated with chrome
|
||
|
5
|
Driven system
|
by chain
|
||
|
6
|
Main motor power
|
7.5 KW
|
||
|
7
|
Cutting type
|
Hydraulic cutting
|
||
|
8
|
Material of cutting
|
CR12 with quench treatment
|
||
|
9
|
Electronic control
|
PLC control
|
||
|
10
|
Hydraulic Station Power
|
4 kw
|
||
Application
-
Industrial Workshop & Warehouse RoofingDouble layer fence roof panels are widely used for industrial workshops and warehouses. Their double-layer structure provides protection and insulation, blocking dust, rain, snow and strong sunlight, and reducing indoor temperature loss. With excellent corrosion and impact resistance, they withstand harsh industrial environments, are easy to install and maintain, and suit large-span industrial buildings.
-
Commercial and Public Building CanopiesThey are applied to canopies of commercial and public buildings. The double-layer design is neat and beautiful, integrating with building styles, and has good waterproof and sun-shading effects. With strong wind resistance, they remain stable in harsh weather, providing a comfortable space for pedestrians.
-
Agricultural Greenhouse RoofingIdeal for greenhouse roofing, the double-layer structure adjusts light transmittance, ensuring sufficient sunlight while blocking harmful UV rays. It maintains stable indoor temperature and humidity, adapts to high-humidity environments, and has a long service life, reducing maintenance costs.
-
Construction Site Temporary RoofingUsed as temporary roofing for construction sites, they effectively block rain, wind and dust, protecting construction materials and workers. Easy to assemble and disassemble, they are reusable, cost-effective and suitable for temporary construction needs.
-
Residential Auxiliary RoofingApplied to residential auxiliary structures (eaves, balconies), they enhance waterproof and sun-shading performance, improve living comfort. The simple and elegant appearance matches residential styles, and they are durable and easy to maintain.
